Solar Calculator and DIY Wiring Diagrams

Jump To Frequently Asked Questions
Jump To Solar Wiring Diagrams

How many solar panels do I need?

Fill out the calculator below to find out how many solar panels you need for your DIY solar panel system. This calculator is meant for camper van conversions, RVs and small off-grid solar systems. Watch the video below if you’re not sure how to fill out the calculator. Head to our electricity main page for further explanations of each solar panel component.

If DIY solar power is intimidating to you, we recommend looking at solar powered generators which are plug and play devices that require little to no wiring.

Read Video Transcript

Hi there parked in paradise visitors! We have a cool solar panel calculator on our site and i’m going to walk you through how to use it because there are a lot of steps involved and sometimes just seeing someone go through it helps quite a bit.

So this is in our solar and electricity guide. And it’s our camper van solar system calculator. This is for all you do-it-yourself (DIY) solar system sizing folks out there.

I’m going to talk a little bit about what it’s good for and what it’s not. And some of the things that are covered in it. Now each of these different subjects in this we cover more extensively in a post on our site so if you’re not able to follow along or have some more questions about some details – those you’ll be able to find elsewhere in the electrical guides on our site.

This is kind of just a guide for how to use the calculator itself and what some of the different numbers and that kind of thing mean.

Now if you’re not familiar with working with electricity at all, you should probably have a professional or a mentor of some kind helping you through this. There’s a lot of little details. 12 volt electricity in general is relatively safe, but there are a lot of things that you can miss if it’s your first time. So it gets a little overwhelming, but it’s not too bad. It’s mostly plug and play and it’s pretty fun doing it on your own not only because you save some money and you can have a system sized exactly to what you need it, but it also helps you diagnose issues later down the road if you know what’s going on.

This calculator kind of walks you through the order that you need to figure things out in when you’re sizing this. So even if you’re not using this calculator itself, this is kind of the direction that you need to go.

The first thing that you need to figure out is all of the components that you’re using in your RV or camper van.

In this case we have a list set up and you can add and delete component lines. What you’re going to want to do is everything that uses electricity, you’re going to write down. What we’re trying to figure out is our daily electrical usage, or our max average.

Because each day is like its own reset in terms of the electricity that you’re going to use. Now there are some cases where for off-grid and storage and stuff things change a little bit, but for an RV or a camper van this is a good starting point.

So in this case we’ll just kind of run through an example camper set up. We have a fridge, and I know this fridge draws 3.9 amps. In solar electrical calculations you can set everything up to figure out your amp hours or your watt hours.

We like to use watt hours because it’s a more accurate estimate of actual power usage, because amps are determined by your voltage. Also some of the newer lithium batteries on the market (if you’re getting a custom Tesla battery or something), those are measured in watt hours.

It’s a more accurate measurement of how much actual electricity you have.

Now a lot of systems use amps just because that’s how 12 volt systems have always been measured in the past, and in vehicles it’s a good transition.

That aside, we know that I have 3.9 amps and this is a 12 volt fridge. So this calculator at the top, if you put your amps and your volts, it does a simple calculation and gives you your watts.

So we’re going to say 47 watts for my fridge.

And I chose kind of a complicated component to start out with. Your fridge is going to be on and plugged in 24 hours per day in a camper van. There is a lot of different components that have variations on this. That fridge when it’s drawing power, it’s powering a compressor and that compressor is only kicking on to cool the fridge down to a certain temp and then that compressor turns off.

This is how the high efficiency fridges and the fridge in your house work. So when that compressor is off, it’s not using electricity even though the fridge is plugged in.

In hotter weather that compressor is going to be on a lot more because that internal temperature is going to raise up a lot. And in cooler weather it might only be on for a few hours a day.

Our fridge on average is running about 8 hours a day. Different fridges run a little different. If you’re in the hot weather all the time you might want to boost that even double it up to 16 hours. But for the most part, ours is running hours per day. We’ve done tests on it, we can see the average.

At night when the temperature drops, the compressor won’t be clicking on and off as much. Our fridge clicks on and off every 10 minutes or so, and then it will run for a few minutes and then it will click off.

And this fridge is running straight off of our batteries. It is a DC powered fridge, so that means it’s plugging right into the DC electrical system. Direct current.

AC components are running off of your inverter.

An inverter is less efficient. So you have to account for that efficiency when we’re counting how much energy we’re using. As you can see, if you run everything DC powered your efficiency is going to be higher in terms of how much power you’re getting out of that. If you run an AC powered object like my laptop, then that efficiency is going to be reduced so you’re going to have to use more energy to charge the laptop than you would if it were DC powered.

So my laptop brick is rated at 170 watts, it’s a big engineering thing, but my laptop itself is rarely ever pulling 170 [watts]. The most I’ve ever seen it pull is 150 [watts] and usually it’s closer to 120 [watts].

Laptops are another variable component in that they’re only pulling their max watts. The watts that you’ll see on that power brick when they’re charging the battery and when they’re running high processing things. So if I’m running a simulation, a 3D simulation then that thing is going to be pumping out 150 or 170 watts.

But if it’s just charging the battery and I’m surfing the internet – 120 [watts]. If it’s not even charging the battery, if it’s just plugged in and idol it’ll be down in the 50 watt range. It doesn’t take much just to run the laptop. What it’s doing is also charging your laptop battery.

Now because of this, my laptop is only plugged in and charging about 2 hours per day. And then the other 2-3 hours that I’m using my laptop it’s running off the battery power that it was charging at 120 watts earlier.

My wife’s laptop is a Macbook and she’s not running as much high processing powered things. So she’s only running about 85 watts and she’s also kind of using it in the same manner. She’ll charge that thing for 2 hours and then she’ll run it for another 3 or 4 because it’s battery is so much better. So it can make a lot better use of that battery.

Now, those of you who are trying to run desktop gaming stations or something in your camper van, you’ll pretty quickly realize that the processing and the CPU and that type of thing in your gaming tower takes a lot of power. Because they’re meant to be plugged into a wall. A gaming laptop is a lot more efficient than one of the towers just because the CPU is designed to be able to run off the battery. So they have to make it kind of reasonable so you can at least run the laptop off the battery for an hour or two of gaming.

We also have two phones, and our phones are I think 3 amps but at 5 volt USB so they’re each running about 15 watts and they’re plugged in 3 hours per day. There’s two of those so we’ll say 6 hours per day.

Vent fan. I think that thing was pulling 2.9 [amps]. These are example numbers, I don’t actually remember exactly what the vent fan is but the numbers are out there somewhere 35 [amp hours].

Cell booster. Oh that vent fan is on maybe 4 hours of the day, at night to cool the van off. And the cell booster, that thing is only running about 2 amps so like 24. And that thing is running about 5 hours per day.

So once you get all of your components listed out, this is all of your electrical things. If you have things like toasters, if you have things like blenders, you’re going to see how quickly those things add up your electricity.

Now one thing I forgot is the laptop and the Macbook are both running off of AC power. So if you notice this number jumps up. From DC it’s 170 watts, accounting for the inefficiency it’s 187 watt hours because it’s running off an inverter. So that’s the amount of power that it needs.

Then we get a total power calculation.

So in this case were using 1127 watt hours per day. Now that’s on our average, high usage day. Some days I might not be running my laptop, some days I might be running a little more. But what I want to do is kind of estimate so I’m not going to be tanking my battery bank every time I use my general lifestyle equipment.

So once you know your total watt hours, the next thing that you need to pick in your system is your battery size. Now your batteries need to be able to discharge this amount of watt hours throughout the day and then we will recharge those with solar.

Your battery can be either AGM and FLA (those are both lead acid battery types). So the AGM is the absorbent glass matt, or flooded lead acid. Both of those have similar profiles in that you don’t want to discharge them more than 50%. If you do that, you’ll start reducing their lifespan significantly.

So an FLA battery can last 8 or 10 years, if you discharge it past 50% every day you’re only going to get about 2 or 3 years out of it.

Batteries are the most expensive component in your electrical system, so you don’t want to wear those out too quickly. You kind of want to make sure that those are running efficiently.

Now if you want to get your batteries to last longer, you can discharge them to only say, 20%. The 20-50% range is where you want to be in. But with a 20% discharge you need a lot bigger battery if you’re only going to be discharging it the same amount.

Now in this battery section we have a total for watt hours as well because a lot of the lithium batteries now are listed in watt hours and like I said, it’s a little more accurate. So in this case, to discharge 1127 watt hours per day, we need a 470 amp hour battery if we only want to discharge it 20%. If we’re ok with discharging it up to 50% we can drop that down to a 185 amp hour battery.

So you’ll notice your battery bank size changes significantly based on your depth of discharge.

We go into this a little more in our battery post, there’s a couple of things you need to keep track of. Your batteries do need to be able to be charged all the way as well so you can’t get too big of a battery bank or else you’ll start losing some of the charging efficiencies and your solar won’t be able to charge up those last few steps.

Now you can also select a lithium battery, and those can be significantly smaller because you can discharge those up to 90-95% without it harming any of the battery. And those don’t even need to be charged up all the way at the end of each day. So they’re a little more flexible in their use. They are also quite a bit more expensive, but they last longer. There’s a lot of benefits to lithium batteries. You kind of get a size difference there so you can either go with a 185 amp hour lead acid style or a 115 amp hour lithium battery.

This is our general recommendation. There’s a little wiggle room, so in this case if you were a little generous with some of your numbers up here, 115 amp hour battery you’re going to find a lot of lithium batteries that are 100 amp hours, you’re probably going to be ok with that. Because your alternative is to jump up to a 200 amp hour lithium battery and spend another grand on that.

So this is just something to keep you aware. Maybe you’ll say hey, maybe I want to trade in my laptop or before I buy a laptop I’ll get one that’s more efficient. Maybe I’ll get one that runs on a 90 watt power brick, and now all of a sudden my lithium battery isn’t quite as taxed by running that laptop.

So once you have your battery, your power storage, you know your power storage can discharge a full day’s use, you can always boost that if you want.

So if you say hey, I’m going to be in Washington I don’t think I’m going to see much sun, I need my battery bank to last a couple of days, or you run critical equipment. If you have sleep apnea and you have a breather that you need on you, you can boost your battery size to make sure that you have juice to run a few days without recharging.

The problem with that is then you also need to make sure you have enough panels to run that once is does drop for two days worth of use.

So after your battery, the next piece of equipment that you choose is your solar panels. You want your solar panels to handle all of the charge throughout the day of your usage. Now your solar panels, they only have a window of opportunity to gather your electricity.

So they can’t supply all of that charge throughout the day like your batteries are going to be able to discharge.

Your solar panels will have a selection down here for how many sun hours you think you’re going to use during the day. We use this a 4 generally for camper vans because if you’re flat mounting your solar panels on top of your van, in most cases they’re only going to see about 4 direct hours of sun.

If you have an angled system, so you can tilt mount your panels towards the sun, you can boost that up to 5 hours. If you’re in the desert southwest and an angled system you’ll have 6-7 hours of available sun.

Say you’re going to travel around sunny climates somehow, maybe you’ll see 7 or 8 hours. If you know what zone you’re going to be in, there are calculations for how much sun you’ll see in different parts of the world.

For the most part, people in RVs are traveling around so that’s too variable to really set how many sun hours you’ll have for sure. This is another generous thing, give yourself some wiggle room here.

So 4 sun hours, gives us 220 watts of solar. That will charge our 1061 watt hours of usage per day. Now, you can always go more solar. There’s no problems with going more solar. This is kind of our general advised minimum. You shouldn’t go below this necessarily.

If you have, let’s say you’re going to be in the desert southwest most of the time and you know you’re going to have tilt mount panels maybe you’ll see 6 hours of sun. You’ll notice that changes your solar panel size calculation.

Go bigger if you can with this, unless you don’t have enough roof space or if you’re on a significant budget. Now the other selection you have to do here is whether or not you’re using a PWM or MPPT controller. Again, we go through all of this on our charge controller post if you want to know details. We do have this in there.

MPPT controllers are more efficient so you need a little less solar panels to get to your watt hour usage. Now, the PWM controllers are significantly cheaper. So sometimes smaller systems, say in this case, let’s say you find a couple of 150 watt hour panels 160 watt panels – if you go 300 watts of solar and a PWM controller, you’re going to be paying less for more power than if you were to go with an MPPT controller. So that’s why we have this choice in here.

Most people are going to be going MPPT unless you’re on a heavy budget or really running the numbers to get the most efficient system possible for your dollar. Than you might be looking at PWM controllers for anything under about 400 watts.

Now our charge controller, this is determined by our solar panel size. So for the charge controller this is a very generous size. Generally, you will be able to go down a size from this. So as you’re picking one out it’s ok to look at the specifications on this.

Say this number comes out to 25 amps, but you know your MPPT specs say that it can go to 240 watts and you only have 220 watts of solar, that charge controller can be a 20 amp charge controller.

This is just a general, you know that the size here is going to work. We can guarantee it for pretty much every situation. Sometimes if you size down it won’t quite work for a few specific panels and that kind of thing.

Ok, next up is the inverter. Now, this inverter number is only going to pop up if you have AC numbers selected. So if you notice when I deselect these DC numbers I’m not running anything off of household power (AC power). That inverter is going to come out blank.

That basically is just saying hey, you can save a lot of money and efficiency by not running an inverter. If you have to run these, this inverter number is our general recommended max size based on your batteries.

So the reason you don’t want to go bigger on your inverter for this is because a bigger power draw is hard on your batteries, it’s going to make them not last as long.

Batteries can handle quick discharges so if you’re running a blender or something for maybe 30 seconds you’ll be fine, but if you’re running a toaster oven or something where you need like a 120W inverter, in this case, you’re not going to be able to run a 120 watt inverter because your battery size isn’t big enough. It will significantly reduce the lifespan of your battery if you’re doing a constant high power draw from it, especially the lead acid battery types.

So if you find that this inverter number, it’s kind of a recommendation, you can go larger. Especially like I said if you’re running short bursts of power. But in general, if you’re going to go significantly larger, you’re going to want to double check your battery bank size.

We see this common mistake pretty often. The other thing to note is you can always go smaller. So in this case, I have two 90 watt DC powered components in my system. Those are the only things I plan on running off the inverter. So I don’t need anything more than a 200 watt inverter.

I might pick up a 400 watt inverter just because they’re easier to find, especially ones that plug into the batteries. But smaller inverters are more efficient. So the smaller you can go comfortably the better with this. You don’t want to grab a massive inverter just in case you want to run a power tool or something off of it.

There’s no reason to do that. If you’re ever going to run a power tool just get a battery powered one or run off of shore power.

You’re not going to want to run a coffee maker and you’re not going to want to run a toaster oven like I said. That’s a lot of the cooking elements that people try to run off inverters. Those things are not great to be battery powered. It’s hard on the batteries. It uses a lot of your juice, your electrical power available.

So this is where that [inverter] number is coming from. It’s based on your battery size.

Alright, so when you’re done with all of that. We don’t save any of your information. So if you’ve done all your calculations and you’ve written down your things. If you want to save all this, down at the bottom of the calculator we have a “print your numbers” button.

That will just print to PDF right there. Save it to your computer.

So we have this calculator here. This is nice to print off to show people. Maybe you’re having an electrician help you install this or maybe you want to share it online with someone. Say hey, here’s all my numbers, this is my daily power usage. These are the component sizes I’m going to go with. It’s a really good quick reference for your camper van.

So once you have that all figured out, how do you put it all together?

We have some solar panel wiring diagrams just for reference here. So, in this case we’ve got 220 watts. You can go down here and, these are all for reference. These are just to see which size components and how you want to plug everything together.

Everyone is going to be different so maybe you’ll find one 240 watt solar instead of two 100 watt panels. A lot of this stuff is variable and that’s why the solar diagrams you see online get kind of wonky and complicated because they’re for very specific set ups.

But this will at least give you an idea of how the components will be acquired together.

We have our solar panels running to our charge controller, our charge controller running to our battery. A lot of people will run off the load terminals to the fuse box. I find that to be a little redundant. Not really necessary in the larger set ups because your battery is better at handling that load anyway.

Either way works, it doesn’t really matter.

And then we have recommended components for those specific sizes. So say we have this fuse box here, you’ll be able to jump in this list of all of the components.

Now the one thing we don’t really list is the wiring because everyone’s wiring is going to be a little different. So this component is our general go-to if we were to build a camper van with our own money this is how we would use it. Sometimes in some cases there are much more expensive but only slightly better components that we don’t find necessary.

I think that should get you going!

6.2K Shares

Watt Calculator (Amps x Volts = Watts)

x =

List Your Devices

Enter number of Watts each device uses and your estimated max hours of use per day. Click the to add a new row. Click the to delete a row. Select whether your device is DC powered or will be using an AC inverter.

DC: AC:

Estimated Watt Hours

This is the maximum power you will expect to use on any given day. If using heaters and fans, it is helpful to do a calculation for a winter month and a summer month (including sun hours below) and use the larger of the two.

Daily Power Usage

0Wh

12V Battery Size

Battery Type

Select whether or not you will be using a Lead-Acid (AGM) or a Lithium battery chemistry. AGM batteries wear out quickly if you use more than 50% of their charge, so they require a larger battery bank to compensate.

AGM or FLA
Lithium
Depth of Discharge (DOD): 50%
AGM or FLA

0Ah

0Wh

Solar Panel Size

Recommended Min Solar Watts

This is the fewest recommended solar power based on the daily power usage and battery size. Check out the FAQ for info on charging while driving and upgrading panels. PWM charge controllers are much cheaper but less efficient than MPPT technology, so they take more minimum solar watts to charge the batteries.

Charge Controller Type:
PWM
MPPT
Estimated Sun Hours:
Solar Watts (PWM)

0W

Charge Controller Size

Charge Controller Size

This is based on your solar panel wattage. It is the smallest size charge controller that you will want to use. Going smaller will be giving up power from your panels. Remember to check the requirements of your specific charge controller to make sure it will work with your panels before buying it.

Charge Controller

0A

Inverter Size

Recommended Inverter Size

This is based on your battery size and is a recommendation of max discharge rate from your devices. If it is significantly lower than your needs, consider getting a larger battery bank to compensate. See the FAQ for further reading on running a larger inverter.

Inverter

0W

Your Solar System

0

12V Battery

0

Min Solar

0

Charge Controller

0

Inverter

Solar Calculator Frequently Asked Questions

How Do I Use This Calculator?

  1. Make a list of your devices
  2. Enter the watts for each device
  3. Enter your estimated hours of use
  4. Select whether it is an AC or DC powered (AC uses an inverter)
  5. Choose which battery type you want to use
  6. Choose your charge controller type
  7. Enter your estimated sun hours (direct sunlight you expect on the panels)

How do I find the Watts of my device?

In most cases you can find the Watts listed online, in the owner’s manual, or on the product itself. In some cases, a product will list Amps and Volts instead.

Remember: Amps*Volts=Watts

If you still don’t know how to find these numbers, read our article on calculating your power usage for each electronic device for some tips and real-world examples.

What if I know my total Wh and just want to get calculations for components?

You can enter it as one component line. Type in your total Wh for “Watts” and 1 for “Hour” and the rest of the solar calculator will function as normal.

Why is my solar system so big?

You are probably still planning to use power like you would in a house. Living in a van requires cutting down on unnecessary electronics as much as possible. The size of your system is directly related to cost. Here are some tips to cut back on electronic use.
Some general rules to follow are:

  • Aim to use as many 12v DC powered electrics as possible
  • Cook efficiently – fuels like propane and butane will make your system smaller than cooking with electricity. Try to cut back on induction burners, coffee makers, crockpots and other high-energy devices
  • Make sure you have the correct hours listed for your refrigerator and electronics. Your fridge will not be running 24 hours per day. In cold weather, the compressor in a fridge may only be running 2-4 hours per day, despite the fridge being on the whole time. In hot climates it may be running as many as 8-16 hours. Similar to laptops and induction burners; they are not usually running at their max rated watts.
  • Look back at your components. See what is drawing the most power and look at ways to reduce or eliminate it.

How much does AC vs DC power change the numbers?

We based our calculations on a 10% efficiency loss that occurs when using an AC inverter.

What is the difference between AGM, FLA and Lithium Batteries?

There are many differences between these batteries. But the main difference (as it relates to this calculator) is the depth of discharge – or DOD.

A lithium battery can be safely discharged up to 90% without shortening its lifespan. AGM and FLA batteries should only be discharged up to 50%. The less you discharge per cycle, the longer the batteries will last.

Because of these discharge rates, you will need a larger AGM or FLA battery for your system than you would with Lithium. You can read more about batteries here.

Can I also charge batteries using my vehicle?

Yes! Absolutely, and it is recommended to supplement any solar system unless you plan on driving infrequently. The best option is a battery to battery charger, many of which double as a solar charge controller. A cheaper option is to go with a battery isolator.

What is the difference between a PWM and MPPT charge controller?

The actionable difference lies in efficiency. A PWM controller uses less complicated and less efficient technology. With that said, for smaller 12V systems, it is often advisable to get a PWM controller and more solar panels get more bang for your buck. We recommend reading our post on charge controllers for more information.

Can I get a bigger charge controller and add more solar panels later?

Yes, this component can benefit from upsizing if you’re not sure if you’ll need more solar or not. With that said, it’s usually a lot of work to add more panels on the road so we like doing them all at once. Check out our article on charge controllers for more in-depth info.

What number should I use for Sun Hours?

The amount of power you get from the sun is determined by how much direct sunlight your panels get. If you are in the sun more often, then you need fewer panels to charge your batteries.

Basing your calculations at 4 sun hours is a good conservative estimate for most van dwellers’ varying lifestyles. If you have tilt-mounted panels or are mostly living in a sunny place like Arizona, then you might need less solar watts because you’ll be getting 5-8 hours of direct sunlight. You are welcome to play around with this number, and even combine it with your winter/summer total watts to see what a comfortable system size is for you.

Do I need an inverter?

No! If you don’t have any AC electronics you do not need an inverter, saving some money and efficiency.

How much lower than the recommended inverter size should I go?

As a general rule, smaller inverters are more efficient. If the biggest item you will be running is a 150W laptop, then getting a 1000W inverter is a waste of money and efficiency. Go with the smallest inverter that you will need with a bit of wiggle room. In this example, a 200W or 300W inverter would be fine for a 150W laptop.

Why is my inverter sized so small? I see other people recommend 1000W+ inverters all the time with a small battery bank.

Battery life is affected by how quickly you are using power. This is relative to how much total capacity the battery has, so larger batteries can discharge more quickly (hence a larger inverter). If you occasionally are using more power – such as a hair drier for a few minutes once a week – then you won’t be doing too much damage to your batteries. But if you’re twice daily using an 1800W induction burner, you’ll want a large battery bank to handle the heavy loads or else will be replacing your expensive batteries quickly. Read our article on inverters for more information. As a side note, the discharge capabilities of lithium batteries are significantly better than those of AGM or FLA.

Why didn’t you list ALL of the components I need? Wires, fuses, ect.

Your wire size is going to vary greatly depending on how far you are running them. Read our wiring guide for more details on how to size your specific system. It is difficult to predict how much wiring each different van build will have and the lengths needed, and we don’t want to have you ordering things that you don’t need.

Ok I got everything, now how do I put it all together?

Awesome! Click on the solar panel wiring diagram below closest to your numbers and get started! If you want more information on electricity, head over to our electrical home page.

This calculator is awesome! How can I support it?

Thanks! We fund our effort and research through affiliate links and advertising, so just by being here and using the site you’re thanking us. We want to share access to this amazing lifestyle with as many people as possible so this solar calculator is our contribution.

6.2K Shares

Solar Panel Wiring Diagrams

Use the wiring diagrams below as a guide to putting together your DIY solar panel system. There are a few different ways to arrange panels, batteries, and connectors. These diagrams are designed to be understood by a beginner for a safe and effective install with readily accessible components.

There are small caveats that an expert may adjust for specific combinations of components to increase longevity or efficiency, but the complexity is overwhelming for a beginner so they are not covered.

If you want to know more, post your specific setup plan to an electrical forum or send us an e-mail to see if you want to make any adjustments.

Click to expand the solar panel wiring diagram closest to your system size

100 Watt solar panel wiring diagram for an RV or camper van

DIY Solar Parts List

Solar Panels (100W)
 Rigid Monocrystalline
 Flexible polycrystalline

Charge Controller
 10A PWM (budget option)
 10A MPPT (most efficient)

Batteries
 75Ah (x1) Battery (AGM option)
 50Ah (x1) Battery (Lithium option)

Inverter
 300W Pure Sine Wave

Additional Parts
 Solar panel roof mounting z-rack (optional)
 Adjustable tilt mount (optional)
 6 circuit fuse block + bus bar
 Battery terminal connectors
 Battery monitor (optional)
 Electrical wire crimp connector
 Solar panel extension cable
 Wires and fuses*

Alternator Charging (optional – choose one)
 Battery isolator
 B2B charger (solar CC included, incompatible with lithium)
B2B charger (compatible with lithium)

100W Solar Panel Kits

Alternatively, you may choose to purchase a pre-configured solar panel kit. Solar kits normally come with solar panels, a charge controller, and z-brackets for mounting.

You will likely need to purchase a battery, inverter, fuses and wires* separately.

Solar Panel Kits
 Renogy 100W Solar Kit (PWM charge controller)
 Renogy 100W Solar Kit (MPPT charge controller)
 WindyNation 100W Solar Kit (PWM charge controller and battery included)

*Fuses and wire gage size are going to vary depend on how long your are running the wires. Read our wiring post to determine the proper wire size for your build.

Zoom 100W Wiring Diagram

200W solar panel wiring diagram for a camper van conversion or RV

DIY Solar Parts List

Solar Panels (100W)
 Rigid Monocrystalline
 Flexible polycrystalline

Charge Controller
 20A PWM (budget option)
 20A MPPT (most efficient)

Batteries
 200Ah (x1) Battery (AGM option)
 100Ah (x1) Battery (Lithium option)

Inverter (use smallest size required)
 600W Pure Sine Wave
 1000W Pure Sine Wave

Additional Parts
 Solar panel roof mounting z-rack (optional)
 Adjustable tilt mount (optional)
 12 circuit fuse block + bus bar
 Battery terminal connectors
 Battery monitor (optional – basic)
 Battery monitor (optional – premium)
 Electrical wire crimp connector
 Solar panel extension cable
 Wires and fuses*

Alternator Charging (optional – choose one)
 Battery isolator
 B2B charger (solar CC included, incompatible with lithium)
B2B charger (compatible with lithium)

200W Solar Panel Kits

Alternatively, you may choose to purchase a pre-configured solar panel kit. Solar kits normally come with solar panels, a charge controller, and z-brackets for mounting.

You will likely need to purchase a battery, inverter, fuses and wires* separately.

Solar Panel Kits
 Renogy 200W Solar Kit (PWM charge controller)
 Renogy 200W Solar Kit (MPPT charge controller)
 WindyNation 200W Solar Kit (PWM charge controller and battery included)

*Fuses and wire gage size are going to vary depend on how long your are running the wires. Read our wiring post to determine the proper wire size for your build.

Zoom 200W Wiring Diagram

300 Watt solar panel wiring diagram for camper and RV

DIY Solar Parts List

Solar Panels (300W)
 Rigid Monocrystalline
 Flexible polycrystalline

Charge Controller
 30A MPPT

Batteries
 150Ah (x2) Battery (AGM option)
 100Ah (x1) Battery (Lithium option)

Inverter (use smallest size required)
 600W Pure Sine Wave
 1000W Pure Sine Wave

Additional Parts
 Solar panel roof mounting z-rack (optional)
 Adjustable tilt mount (optional)
 12 circuit fuse block + bus bar
 Battery terminal connectors
 Battery monitor (optional – basic)
 Battery monitor (optional – premium)
 Electrical wire crimp connector
 Solar panel extension cable
 Wires and fuses*

Alternator Charging (optional – choose one)
 Battery isolator
 B2B charger (solar CC included, incompatible with lithium)
B2B charger (compatible with lithium)

300W Solar Panel Kits

Alternatively, you may choose to purchase a pre-configured solar panel kit. Solar kits normally come with solar panels, a charge controller, and z-brackets for mounting.

You will likely need to purchase a battery, inverter, fuses and wires* separately.

Solar Panel Kits
 Renogy 300W Solar Kit (PWM charge controller)
 WindyNation 100W Solar Kit (PWM charge controller and battery included)

*Fuses and wire gage size are going to vary depend on how long your are running the wires. Read our wiring post to determine the proper wire size for your build.

Zoom 300W Wiring Diagram

Installing a DIY 400 Watt solar panel system on a camper van or RV. Wiring diagram.

DIY Solar Parts List

Solar Panels (400W)
 Rigid Monocrystalline
 Flexible polycrystalline

Charge Controller
 40A MPPT (budget)
 40A MPPT (premium)

Batteries
200Ah (x2) Battery (AGM option)
 100Ah (x2) Battery (Lithium option)

Inverter (use smallest size required)
 600W Pure Sine Wave
 1000W Pure Sine Wave
 1500W Pure Sine Wave

Additional Parts
 Solar panel roof mounting z-rack (optional)
 Adjustable tilt mount (optional)
 6 way fuse block + bus bar
 Battery terminal connectors
 Battery monitor (optional)
 Electrical wire crimp connector
 Solar panel extension cable
 Wires and fuses*

Alternator Charging (optional – choose one)
 Battery isolator
 B2B charger (solar CC included, incompatible with lithium)
 Battery isolator (compatible with lithium)
 B2B charger (solar CC included, compatible with lithium)

400W Solar Panel Kits

Alternatively, you may choose to purchase a pre-configured solar panel kit. Solar kits normally come with solar panels, a charge controller, and z-brackets for mounting.

You will likely need to purchase a battery, inverter, fuses and wires* separately.

Solar Panel Kits
 Renogy 400W Solar Kit (PWM charge controller)
 WindyNation 100W Solar Kit (PWM charge controller and battery included)

*Fuses and wire gage size are going to vary depend on how long your are running the wires. Read our wiring post to determine the proper wire size for your build.

Zoom 400W Wiring Diagram

Wiring diagram for a DIY solar panel system on an RV or camper van conversion

DIY Solar Parts List

Solar Panels
 Rigid Monocrystalline
 Flexible polycrystalline

Charge Controller
 40A MPPT (budget)
 40A MPPT (premium)

Batteries
 400Ah 6v (x4) AGM Battery

Inverter (use smallest size required)
 600W Pure Sine Wave
 1000W Pure Sine Wave
 1500W Pure Sine Wave

Additional Parts
 Solar panel roof mounting z-rack (optional)
 Adjustable tilt mount (optional)
 6 way fuse block + bus bar
 Battery terminal connectors
 Battery monitor (optional)
 Electrical wire crimp connector
 Solar panel extension cable
 Wires and fuses*

Alternator Charging (optional – choose one)
 Battery isolator
 B2B charger (solar CC included, incompatible with lithium)
 Battery isolator (compatible with lithium)
 B2B charger (solar CC included, compatible with lithium)

Large Solar Panel Kits

Alternatively, you may choose to purchase a pre-configured solar panel kit. Solar kits normally come with solar panels, a charge controller, and z-brackets for mounting.

You will likely need to purchase a battery, inverter, fuses and wires* separately.

Solar Panel Kits
 ECO-WORHTY 600W Solar Kit
 ECO-WORTHY 800W Solar Kit

*Fuses and wire gage size are going to vary depend on how long your are running the wires. Read our wiring post to determine the proper wire size for your build.

Zoom Wiring Diagram

Large DIY solar panel system wiring diagram for an RV or camper van conversion. Great ideas for off grid living solar power.

DIY Solar Parts List

Solar Panels
 Rigid Monocrystalline
 Flexible polycrystalline

Charge Controller
 40A MPPT (budget)
 40A MPPT (premium)

Batteries
 100Ah 12v (x4+) Lithium Battery

Inverter (use smallest size required)
 600W Pure Sine Wave
 1000W Pure Sine Wave
 1500W Pure Sine Wave

Additional Parts
 Solar panel roof mounting z-rack (optional)
 Adjustable tilt mount (optional)
 6 way fuse block + bus bar
 Battery terminal connectors
 Battery monitor (optional)
 Electrical wire crimp connector
 Solar panel extension cable
 Wires and fuses*

Alternator Charging (optional – choose one)
 Battery isolator
 B2B charger (solar CC included, incompatible with lithium)
 Battery isolator (compatible with lithium)
 B2B charger (solar CC included, compatible with lithium)

Large Solar Panel Kits

Alternatively, you may choose to purchase a pre-configured solar panel kit. Solar kits normally come with solar panels, a charge controller, and z-brackets for mounting.

You will likely need to purchase a battery, inverter, fuses and wires* separately.

Solar Panel Kits
 ECO-WORHTY 600W Solar Kit
 ECO-WORTHY 800W Solar Kit

*Fuses and wire gage size are going to vary depend on how long your are running the wires. Read our wiring post to determine the proper wire size for your build.

Zoom Wiring Diagram

Additional information on choosing components

Vanlife Charge Controller

Battery Charging

Camper Van Electricity

Visit our Electricity Main Page to see all of our camper van electrical posts. There is further reading on all parts of the system, extras to install tips and advice on all things electric!

Electricity Main Page

Visit ParkedInParadise.com/solar-calculator for more information

This Post Has 32 Comments
  1. Thank you for such a well laid out info site, W/ LINKS! I’m using 2- 100 Ah AGM battery’s that I’ve wired together in paralell w/ 2, 8 gauge cables. I’m WAY over powered as I only use 3 low wattage fans and recharge my tablet and phone. I recharge with a NOCO GENIUS that i hook up and plug in at work, which is an amenity they allow, a grace of God really. I’m looking to eventually hook up a refigerator/ freezer, around 25 quarts? Hence the large batts. I reside in my van all year when not at my sister’s down the street. I’m able to save alot of money on rent this way, and thanks to being knowledgeable about electricity/electronics, I’m very comfortable.

  2. Great article Very good explanation of solar basics. I would like to know how I add alternator charging as I drive as well as shore power charging at RV parks. Also any tips on mounting ridged palels to roof. Is some type of rubber flex system a good idea?

  3. Thank you so much!

    I love a good spreadsheet/ calculator and was having trouble pinning down what i need for my campervan! You have saved me alot of effort 🙂

  4. Hi can anyone tell me where I can buy a cassette toilet /washand basin/shower unit complete for the back of a sprinter. Regards, Get.

  5. I plan on building a skoolie in the future, and am toying with the idea of running 24v instead of 12v. This is a helpful starting point for me to figure out what I need. If I use this to calculate, would I just halve the Ah needed for the battery for a 24v setup?

  6. In your 400W diagram, you have the following battery recommendations:

    200Ah (x2) Battery (AGM option)
    100Ah (x1) Battery (Lithium option)

    Would you not want 200Ah with the lithium option? I know they can be discharged more than their AGM counterparts, but that still seems rather low. Thoughts?

    And thanks for all the great detail in your excellent guides!

  7. Your calculator is GREAT! – But I do have a question about the panel diagram. If each panel is 12V – why would they be wired in SERIES to obtain increased wattage (but not voltage). If 300 watt diag (for example) you would have 12v X 3 = 36 volts. Going into a solar controller rated at 12v. Am I missing anything on this basic “volts in series = all volts sum”? Thanks! Great site!

    1. Andy-

      Thanks for the comment, it shows you understand the Amps x Volts = Watts equation. I think you meant increased amperage (not voltage), but I get the general question and it is a good one to ask! The voltage of the solar controller is the rated output of the controller. The input depends on many variables but is generally always higher. “12V” solar panels typically output between 18-22V, which fluctuates based on external factors (sun, temperature, angle, etc). The CC takes that fluctuating energy and turns it into a tame charge voltage that the batteries can handle. For a 12V battery bank, this will be between 13.5V and 14.8V depending on where the batteries are at in the charge cycle.

      So, with that said, an MPPT charge controller has the ability to “convert” the extra voltage above that charge level to amperage, thus using as much energy as possible for charging the batteries. The charge controller can do this with 18V or 24V or 36V or a range of voltage inputs (depending on the controller) and use it to charge 12V batteries. Meaning that you get the same amount of theoretical power from two 100W panels in series as you do from two 100W panels in parallel when using an MPPT controller. I say theoretical because in many ways wiring panels in series is slightly more efficient than wiring them in parallel. There is more detail in this in our charge controller article if you want to know. Certain circumstances benefit from wiring in parallel, but our default is to wire in series. Hope this helps!

      1. Thanks Ian, I did not know that the CC would step down in those cases. So in my application, I have a 12V motor that will use 12 amps (144 watts) for 8-10 hours a day. Using your calculator, rounding up with worst case, I will need a 12v 200 ah battery and 300 watts of panels. So in this case, 100 watt, 12V panels in parallel will give: 12 v (12 to 18v) and 300 watts out total. But you suggest in series I’ll then have 36v (12+12+12v) and still 300 watts out? I would then use the CC to step to the 12v needed to charge the battery. In series wouldn’t the CC stepping down use some of the potential power? – I will check out your charge control article next. Thanks for your input!!

  8. do you have any information for using three inputs? Solar, Alternator and shore power. Also, is there a good way to get power use estiments for devices? example: looking at a microwave that says it uses 720 watts. Im guessing thats for the durration of use? so I use it for 10 minutes, thats 0.6 of an hour so 720/0.6 = wH of use? Or a refrigerator that cycles during the day.

    Im in the planning pase as you may have guessed. Thanks for your work, its the best place for information I have found.

  9. Umm… New guy here, but I thought I might point out an error. On the drawing for the Large Systems: Wiring Diagram (AGM Batteries), you will want to correct the battery wiring so nobody catches a face-full of acid. You have two batteries in series (24v) and they are in parallel with a single battery (12v.) And those are in series with the first battery. Oops…

    I plan on powering my pop-up Skamper using a 40A MMPT controller, and a 1000W Pure Sine Wave inverter. I’m purchasing a single 12V/100W panel and a single 50Ah AGM just to get started. With the beefy internals, I figure, I can add more panels and batteries later. This is my first solar project. Just want to charge some phones at night and make coffee in the morning. the system can recharge the batteries the rest of the day.

    1. Similar thoughts… but I’m struggling with the charge controller sizing myself… given other elements are fixed (due to size).

      I’m running four 100 watt panels… 2 series of 2 (alternating in my rooftop real estate – a 5ft x 7ft trailer) combined in parallel into the charge controller.

      At first I was gonna run 2 battery banks (as I don’t have same batteries/ ages/use cases, types) but this build is turning into a nightmare (even though I can isolate them for charging – but only PWN chargers can I find with dual battery outputs that never charge simultaneously – bad for different batteries).

      Now I’m thinking scrap the [free] group 27 deep cycle battery with ~80 amp-hours capacity and just going with 3 (maybe 4) 35 amp-hour AGM in parallel (again a space issue – fitting “short” batteries under the frame).

      At first I thought 20 amp CC was good enough 18 volts x 2 = 36 volts (series) and 5.5 amps x 2 = 11 amps (parallel) into the CC… but everywhere I’m reading seems to indicate I’ll somehow be shedding massive volts down to 14 +/- 0.5

      Any of my wire runs are no more than 6-8 ft… so #12 AWG should be fine for wiring, but I’m way confused on this current/amp boost that will happen between CC and batteries in a 12 volt system???

      Is a 20 amp CC rated for input or output???

      1. Hans,

        In you situation, you would indeed be dropping significant voltage because of your choice of PWM controller. PWM controllers don’t have the ability to “step down” voltage, they essentially just throw it away. So, you have two choices: 1) wire your panels all in parallel instead of 2S2P. This would make your input at 18V and you would be getting more advantage of a PWM controller without loosing significant power. You would need about a 30A PWM in this case, but I think it is a good option for your scenario and budget. 2) Get a MPPT charge controller. This is the more expensive option, but allows more flexibility in input wiring.

        The 20amp is the output rating for a CC.

        For batteries, my choice would be to scrap the old ones. It’s possible that it would work out, but there is a significant chance that they will end up costing you more in the long run and cause frustration on the road. Make sure you wire your batteries in a parallel string that maximizes their lifespan: http://www.smartgauge.co.uk/batt_con.html

  10. I am looking to do the 400 watt hook up, I understand how each component is to be placed but what I am having trouble with is the size of wire to use from the solar panels to the Battery bank, and then to the fuse block to run for the lighting and plugs to power some of the equipment like the cell phone and laptop. so is there a book and or a diagram that helps explain this from each unit.

  11. My camper is stationary (used as a permanent camp) and off grid. I am looking at getting Solar and all of the installs suggest connecting to the existing wiring inside the camper. Is there any reason I cannot simply connect the solar to batteries outside the camper, and connect the Shoreline to the inverter? Seems to me that this would not only run the A.C units but would also charge the batteries inside the trailers. Is there any down side to this approach?

  12. Excellent page guys, nice work. I wish I had come across this 2 years ago when I was building out my van and trying to figure out all this stuff. 2 years later I’ve learned a lot too!

    I’m resizing now due to an oversight in my original plans. Don’t underestimate cloudy days! I live in CO and travel a lot West and South, I sized expecting nearly unlimited sunny days. But alas, after 2 days of clouds I’m struggling with my power consumption. Despite having 400 watts of panels on the roof, on a cloudy day I’m lucky to make 4 amps, less if the clouds are extra thick and nothing if raining.

    I’m looking now to drop $2,500 on lithium to solve my problems 8-D I’m thinking about 300 AH of lithium is enough to get me through several days of making no or little power. And on days I do get it, I can put out my 5th portable panel and dump 20 AMPS an hour into the lithium’s when I can. It’s just so crazy expensive.

    I use a good bit of power because I work from my van. So I use about 8 amps to run my laptop, second monitor and play music. The refer uses 5 amps, but cycles hourly, so guessing it’s using 2.5 amps an hour, depending on temperature of the van of course. Not to mention fans and other incidentals, and losses throughout the system.

    Now I’m wondering, and what brought me to your site, is if there’s a benefit from multiple batteries? I can get the amps I want using 1, 2, 3, or more batteries. Thinking if I have just 1 and it stops working for some reason, then I have no reserve. If I have 3 and one stops working, I can re-wire in the field with the 2 remaining? Are there losses with multiple batteries?

    I know with lead batteries, you’re supposed to use the same year, etc, I don’t know if that’s true for Lithium. For instance, can I buy 2 lithium batteries now and add more a few years down the road?

    Sadly I’ll be ditching my $800 worth of 200 AH AGM batteries for lithium.

  13. First, Thanks for sharing your knowledge. My question is the AC charger for an electronic device has 0.50A input and 1.67A or 2.0A output, do I use the input or output number for solar sizing?

    Thanks

  14. Really nice and simple calculator but limited to summer use, what I need to know is what kind of drop off would there be in winter, I need this so I can build a system for use 365 days of the year.

    1. Hey Andy, for winter camping, adjust the list of devices and number of sun hours. For example: a refrigerator might be running 8 hrs/day in the summer, but only 4 hrs/day in the winter. If you’re running things like an electric heater, include that in your list of devices for winter.

      Winter sun hours will be less than summer ones. You can put your location in a site like this: https://www.wholesalesolar.com/solar-information/sun-hours-us-map to find the average sun hours per day. If you’re changing locations frequently, we like to use 3.5-4.5 sun hours for winter.

      We recommend calculating both your summer and winter numbers. Then build your system to the largest number.

  15. I’m concerned about the solar_factor variable you use to compute the required power output from the solar panels. If I am consuming a certain amount of power throughout the day, then the solar panels alone must be able to source that power. So why is solar_factor greater than 1? Why should it be as high as 1.2 for a PWM controller or 1.3 for an MPPT controller?

    I understand possibly amortizing varying power usage over multiple days, but then you would need a larger battery system to support that.

    Is it to account for solar panel power output during sunrise and sunset? If so, that should be a constant increase instead of a multiplier.

    1. Ned,

      You’re looking at the formulas, I assume?

      These calculations are mitigating the inefficiencies of the solar system. I haven’t pulled up the formula to look at the function (I don’t read the script very well, but I do triple check that all of the math is correct). Remember that the calculator is determining what system size that you need based on your inputs (not how much output you will get from an existing system). A 100W solar panel plugged into a PWM controller will not be putting in 100W of power to your batteries. Due to the controller needing to adjust voltage to charge properly, some power is lost to the system. So we mitigate for that effect by estimating more solar. For instance, if you need 150W of power, but your system is only 75% efficient, then you would need 200W of panels to get 150W into the batteries. The numbers you’re looking at function in this purpose. I’m not sure exactly where in the formula the 1.2 and 1.3 come in the way we set up the calculator (it was awhile ago), but you’ll notice that with an MPPT system, you need less wattage in panels than a PWM one because MPPT controllers are more efficient.

      If you want me to dig up the formula, let me know, it’ll just take some effort on my part.

  16. Thanks so much for the thorough diagrams!

    I have a setup that’s going to be all DC, no AC required. I have the same solar charge controller shown in your diagram, but I can’t find the specs for it. You show the loads directly tied to the battery. Can you confirm that the wiring can be setup so that the fuse block / load can be wired directly through the controller?

    1. Katie-

      Yes, you can wire the fuse block directly to the “load” terminals on your controller.

      If you’re asking if you can do this without a battery, then the answer is no. You still need the CC wired to a battery through the battery terminals. The battery is essential for the system, not just to store energy but to create a balanced energy source (rather than the erratic energy that comes from the sun). The “load” terminals on the CC are in fact pulling energy from the battery, not the solar panels.

Leave a Reply

Your email address will not be published. Required fields are marked *

Back To Top
6.2K Shares
Share
Pin
Tweet
Reddit
